NEC M403W User Manual

66
3. Convenient Features
⓭ Viewing 3D Images
Theprojectorprovides3DimagestoauserwearingcommerciallyavailableLCDshuttereyeglasses.
CAUTION
Health precautions
Beforeviewing,besuretoreadhealthcareprecautionsthatmaybefoundintheuser’smanualincludedwithyourLCD
shuttereyeglassesoryour3DcompatiblecontentsuchasDVDs,videogames,computer’svideolesandthelike.
Toavoidanyadversesymptoms,heedthefollowing:
• DonotuseLCDshuttereyeglassesforviewinganymaterialotherthan3Dimages.
• Allowadistanceof2m/7feetorgreaterbetweenthescreenandauser.Viewing3Dimagesfromtooclosea
distancecanstrainyoureyes.
• Avoidviewing3Dimagesforaprolongedperiodoftime.Takeabreakof15minutesorlongeraftereveryhour
ofviewing.
• Ifyouoranymemberofyourfamilyhasahistoryoflight-sensitiveseizures,consultadoctorbeforeviewing3D
images.
• Whileviewing3Dimages,ifyougetsicksuchasnausea,dizziness,queasiness,headache,eyestrain,blurry
vision,convulsions,andnumbness,stopviewingthem.Ifsymptomsstillpersist,consultadoctor.
• View3Dimagesfromthefrontofthescreen.Viewingfromananglemaycausefatigueoreyestrain.
LCDshuttereyeglasses(recommended)
• UsecommerciallyavailableDLP
®
LinkorothermethodcompatibleLCDshuttereyeglasses.
Stepsforviewing3Dimagesontheprojector
1. Connecttheprojectortoyourvideoequipment.
2. Turnontheprojector,displaytheon-screenmenu,andthenselect[ON]forthe3Dmode.
 Fortheoperatingproceduretoturnonthe3Dmode,referto“On-screenmenufor3Dimages”onthefollowing
page.
3. Playyour3Dcompatiblecontentandusetheprojectortodisplaytheimage.
4. PutonyourLCDshuttereyeglassestoview3Dimages.
Also refer to the user’s manual accompanied with your LCD shutter eyeglasses for more information.
On-screenmenufor3Dimages
Followthestepstodisplaythe3Dmenu.
1. Press the MENU button.
The on-screen menu will be displayed.
2. Press the ▷buttontwice.
The [SETUP] menu will be displayed.
[M403W/M363W/M323W/M403X/M363X/M323X/
M283X/M403H/M323H]
[M353WS/M303WS/M333XS]

NEC M403W Specifications

General

Native aspect ratio	16:10
Projection distance	0.76 - 13.53 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	DLP
Supported aspect ratios	16:10, 16:9
Contrast ratio (typical)	10000:1
Screen size compatibility	30 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	-25 - 25 °
Focus	Manual
Throw ratio	1.2 - 2.04:1
Zoom capability	Yes
Focal length range	17.09 - 29.05 mm
Aperture range (F-F)	2.4 - 3.1
Lamp power	270 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Lamp power (economic mode)	162 W
Service life of light source	5500 h
Service life of light source (economic mode)	8000 h
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, SECAM
Supported graphics resolutions	640 x 480 (VGA), 720 x 576, 800 x 600 (SVGA), 832 x 624, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1152 x 870, 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1360 x 768 (WXGA), 1376 x 768, 1440 x 1050, 1440 x 900 (WXGA+), 1440 x 900, 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
DVI port	No
Composite video in	1
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Maximum digital resolution	1920 x 1080 pixels
Noise level	30 dB
Certification	CE; EAC; Gost-R; TÜV GS
RMS rated power	20 W
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	335 W
Power consumption (standby)	0.4 W
Power consumption (typical)	278 W
Power consumption (economy mode)	246 W
Power consumption (network standby)	2.9 W
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	RoHS
Cables included	AC, VGA
Remote control type	IR

Weight and Dimensions

Depth	285.9 mm
Width	367.9 mm
Height	97.5 mm
Weight	3600 g
