SPECIFICATIONS
This section provides technical information about MT1060R/MT860R projector's performance.
Model Number MT1060R/MT860R
Optical
LCD Panel 1.0" p-Si TFT active-matrix
Resolution MT1060R: 1024⳯768 pixels up to UXGA with Advanced AccuBlend
MT860R: 800⳯600 pixels up to UXGA with Advanced AccuBlend
Lens Short-throw fixed-focus lens, 1:1
F1.9, f=20.2mm
Lamp MT1060R: 275 W DC Standard
MT860R: 160 W DC Extended life lamp
Image Size 50 inches - 100 inches (1.27 m – 2.54 m) diagonal
Projection Distance 38" – 79" / 0.98m – 2.0m
Projection Angle 0 degree
Electrical
Inputs 2 RGB (D-Sub 15 Pin/BNC⳯5), 1 DVI (MT1060R only), 1 S-Video, 1 Video, 2 PC Card, 3 Stereo Mini Audio, 2 (L/
R) RCA Audio,
1 PC Control, 1 (L/R) RCA Audio
Outputs 1 RGB, 1 Stereo Mini Audio
USB Port 1 A Type, 1 B Type
Video Compatibility NTSC, NTSC4.43, PAL, PAL-60, PAL-N, PAL-M, SECAM, HDTV:1080i, 720p, 480p, 480i (w/optional cable)
Scan Rate Horizontal: 15 kHz to 100 kHz (RGB: 24 kHz or over) / Vertical: 48 Hz to 120 Hz
Video Bandwidth RGB: 80 MHz (-3dB)
Color Reproduction 16.7 million colors simultaneously, Full color
Horizontal Resolution NTSC / NTSC4.43/PAL/PAL-M/PAL-N/PAL60: 550 TV lines
SECAM: 350 TV lines
YCbCr: 800 TV lines
RGB: MT1060R: 1024 dots (H)⳯768 dots (V), MT860R: 800 dots (H)⳯600 dots (V)
External Control RS232, IR, USB, LAN (optional)
Sync Compatibility Separate Sync / Composite Sync / Sync on G
Built-in Speakers 5W⳯2 (stereo)
Power Requirement 100 - 120V AC / 200 - 240V AC, 50 / 60 Hz
Input Current 4.0A (100 - 120V AC) / 2.0A (200 - 240V AC)
Power Consumption 1.0W Standby mode/390W Lamp Normal mode / 320W Lamp Eco mode (250W optional Extended Life lamp)
Mechanical
Installation Orientation: Desktop/Front, Desktop/Rear, Ceiling/Front, Ceiling/Rear
Dimensions 13.2" (W)⳯4.5" (H)⳯12.7" (D)
334mm (W)⳯115mm (H)⳯323mm (D)
(not including protrusions)
Net Weight MT1060R: 14.0 lbs / 6.3 kg, MT860R: 13.0 lbs / 5.9 kg
Environmental Considerations
Operational Temperatures: 32°F to 104°F (0°C to 40°C), 20% to 80% humidity (non-condensing)
Storage Temperatures: 14°F to 122°F (-10°C to 50°C), 20% to 80% humidity (non-condensing)
Regulations UL Approved (UL 60950, CSA 60950)
Meets DOC Canada Class B requirements
Meets FCC Class B requirements
Meets AS/NZS3548 Class B
Meets EMC Directive (EN55022:1998, EN55024-1998, EN61000-3-2, EN61000-3-3)
Meets Low Voltage Directive (EN60950, TUV GS Approved)
For additional information visit:
US : http://www.necvisualsystems.com
LCD panels are inherently susceptible to pixel defects.
For additional information regarding pixel data, please contact your local NEC sales office.
The specifications are subject to change without notice.
