To attach the MultiSync E500/E700 monitor to your system, follow these
instructions:
1. Turn off the power to your computer and MultiSync monitor.
2. If necessary, install the display card. For more information,
refer to the display card manual.
3.
For the PC:
Connect the MultiSync E
500
/E
700
monitor’s
video cable to the display card’s connector on the computer.
Tighten screws on all connectors.
For the Mac:
Connect the MultiSync Macintosh Cable
Adapter to the monitor’s connector on your computer.
Connect the MultiSync E
500/E700 monitor’s signal cable to
the other end of the cable adapter. Tighten screws on all
connectors.
4. Connect one end of the power cable to the MultiSync
E
500/E700 monitor and the other end to the power outlet.
5. Turn on your MultiSync monitor and computer.
6. This completes the installation.
NOTE: If you have any problems, please refer to the
Troubleshooting section of this manual.
Connection to Your Personal Computer E - 9
