Video Out Connection
Connector
DisplayPort1 DisplayPort2 HDMI1 HDMI2 OPTION
DisplayPort1 DisplayPort2 HDMI1 (ARC) HDMI2 DisplayPort Slot TMDS Slot COMPUTE MODULE
DisplayPort
Yes Yes No No Ye s No No
HDMI
Yes*
1
Yes*
1
Yes Yes Yes*
1
Yes Yes
*
1
: By inputting [DP TO HDMI CONVERT] is set to [ENABLE], the DisplayPort input can be HDMI output.
DP and HDMI cannot be output simultaneously.
NOTE:  • Video Out cannot be performed when [MULTI PICTURE] or [QUICK INPUT CHANGE] are enabled.
For connecting multiple monitors with HDMI cable
• Use the same monitor model.
• Set the same ([MODE1] or [MODE2]) at [HDMI MODE] in [INPUT-ADVANCED] in all connected multiple monitors.
For HDMI Out and DisplayPort Out
• Select DisplayPort1, DisplayPort2 or OPTION input for the monitor to output a signal from DisplayPort Out.
• Select either the HDMI1, HDMI2 or OPTION input for the monitor to output a signal from HDMI OUT.
• If [DP TO HDMI CONVERT] is set to [ENABLE], even when the OSD menu “INPUT” is set to [DisplayPort1] or [DisplayPort2],
the video is output from the HDMI output connector. In this case, the video output of the DP output connector will stop.
• This monitor’s signal output function supports contents protected by HDCP.
HDCP content can be distributed across multiple connected monitors as described below:
• HDCP1.3/1.4: Up to 8 monitors (including this monitor).
• HDCP2.2: Up to 5 monitors (including this monitor).
• The time until image is shown depends on the number of connected monitors.
• Without HDCP: Up to 9 monitors (including this monitor).
• When [DUAL DAISY CHAIN MODE] is set to [ENABLE], HDMI and DisplayPort can be output simultaneously.
However, one input cannot be output to both HDMI and DisplayPort at the same time.
Example:
• Even when [DUAL DAISY CHAIN MODE] is set to [ENABLE], DisplayPort1 cannot be output simultaneously from both
HDMI out and DisplayPort out.
• When [DUAL DAISY CHAIN MODE] is set to [ENABLE], DisplayPort1 can be output from DisplayPort out and HDMI2
can be output from HDMI out.
NOTE:  • Do not turn the main power switch off/on or connect/disconnect the cable while playing HDCP-protected video
content in a daisy chain connection. Playback of video content may stop. If playback stops, try playing again.
• Depending on the device you use, the number of monitor connections will change.
• When showing an image in a multi-monitor setting, do not disconnect cables from the monitors. When you
disconnect cables, please turn the main power off rst.
