Mounting the Projector
11
NOTE : Mounting boards, M8-type anchor nuts, bolts, nuts and washers are commercially
available.
Mounting board
(Strong enough to support the weight of the whole unit.)
Nut and washer
Beam
Nut and washer
Bolt (M8)
Anchor nut (Purchase commercially-available M8-type anchor nuts
that are strong enough to endure the weight of the whole unit.)
Ceiling
Bolt (M8)
Nut and washer
■When the Ceiling is Wood Construction:
■When the Ceiling is Concrete Construction:
Installation Examples
