Mounting the Projector
Attach the Fixed Ceiling Part to the Ceiling
First, partially tighten the four screws, then tighten the screws
firmly after positioning.
Use M8 bolts for the fixed ceiling part.
Use of types other than M8 could
cause the projector to fall.
WARNING!
Fixed ceiling part
2
Attach the Projector Mounting
Adapter to the Projector
Remove the one screw from the front panel
and open the projector mounting adapter.
Use three M4 screws to mount the
projector mounting adapter.
Next, close the projector mounting adapter
and tighten the one screw on its side.
Be careful not to catch your fingers
when opening or closing the
projector mounting adapter.
Please use the specified screws;
use of screws other than those
specified may damage the projector.
WARNING!
M4
M4
