NEC NP100 - Compatibility Modes

36
English ...
Appendices
Compatibility Modes
Modes Resolution
V.Frequency
(Hz)
H.Frequency
(kHz)
VGA 640 x 480 60 31.50
640 x 480 72 37.90
640 x 480 75 37.50
640 x 480 85 43.30
720 x 400 70 31.50
720 x 400 85 37.90
SVGA 800 x 600 56 35.20
800 x 600 60 37.90
800 x 600 72 48.10
800 x 600 75 46.90
800 x 600 85 53.70
XGA 1024 x 768 60 48.40
1024 x 768 70 56.50
1024 x 768 75 60.00
1024 x 768 85 68.70
SXGA 1152 x 864 70 63.80
1152 x 864 85 77.10
* 1152 x 864 75 67.50
1280 x 1024 60 63.98
* 1280 x 1024 72 76.97
* 1280 x 1024 75 79.98
SXGA+ * 1400 x 1050 60 63.98
Power Mac G4 640 x 480 66.6 (67) 34.93
800 x 600 60 37.90
1024 x 768 60 48.40
1152 x 870 75 68.68
* 1280 x 960 75 75.00
PowerBook G4 640 x 480 60 31.35
640 x 480 66.6 (67) 34.93
800 x 600 60 37.90
1024 x 768 60 48.40
1152 x 870 75 68.68
* 1280 x 960 75 75.00
i Mac DV 1024 x 768 75 60.00
1152 x 870 75 68.49
Note: “*” for XGA
model only.
Note: Shaded signals
are compressed with
scaling technology.
Note: The projector
only support a separate
sync signal. Composite
sync and sync on green
are not supported.
