1. Introduction
➌
Part Names of the Projector
Zoom Lever
(→ page 22)
Controls
(→ page 6)
Lens
Lens Cap
Built-in Security Slot (
)*
Adjustable Tilt Foot Button
(→ page
21)
Adjustable Tilt Foot
(→ page
21)
Remote Sensor
(→ page
8)
Front/Top
AC Input
Connect the supplied power cable's three-pin plug here, and plug
the other end into an active wall outlet. (→ page 15)
Terminal Panel
(→ page
6)
Rear
* This security slot supports the MicroSaver ® Security System. MicroSaver ® is a registered trademark of
Kensington Microware Inc. The logo is trademarked and owned by Kensington Microware Inc.
Ventilation (outlet)
Heated air is exhausted from here.
Focus Sensor
(→ page
22, 47)
Ventilation (inlet)
Ventilation (inlet)
