7. Appendix
➎
Compatible Input Signal List
Signal Resolution Frequency H. Refresh Rate
( Dots ) ( kHz ) ( Hz )
NTSC – 15.73 60.00
PAL – 15.63 50.00
PAL60 – 15.73 60.00
SECAM – 15.63 50.00
VESA 640 × 480 31.47 59.94
IBM 640 × 480 31.48 59.95
MAC 640 × 480 35.00 66.67
VESA 640 × 480 37.86 72.81
VESA 640 × 480 37.50 75.00
IBM 640 × 480 39.38 75.00
VESA 640 × 480 43.27 85.01
IBM 720 × 350 31.47 70.08
VESA 800 × 600 35.16 56.25
VESA 800 × 600 37.88 60.32
VESA 800 × 600 48.08 72.19
VESA 800 × 600 46.88 75.00
VESA 800 × 600 53.67 85.06
MAC 832 × 624 49.72 74.55
VESA 1024 × 768 48.36 60.00
VESA 1024 × 768 56.48 70.07
MAC 1024 × 768 60.24 74.93
VESA 1024 × 768 60.02 75.03
VESA 1024 × 768 68.68 85.00
# SUN 1152 × 900 61.80 65.95
# VESA 1280 × 960 60.00 60.00
# VESA 1280 × 1024 63.98 60.02
# MAC 1280 × 1024 69.87 65.18
# SXGA+ 1400 × 1050 – 60.00
# VESA 1600 × 1200 75.00 60.02
# VESA 1600 × 1200 87.50 70.00
# VESA 1600 × 1200 93.75 75.00
#
HDTV (1080i) 1920 × 1080 33.75 60.00 Interlace
#
HDTV (1080i) 1920 × 1080 28.13 50.00 Interlace
#
HDTV (720p) 1280 × 720 45.00 60.00 Progressive
#
HDTV (720p) 1280 × 720 37.50 50.00 Progressive
SDTV(576p) – 31.25 50.00 Progressive
SDTV (480p) – 31.47 59.94 Progressive
DVD YCbCr – 15.73 59.94 Interlaced
DVD YCbCr – 15.63 50.00 Interlaced
# : Signals above  agged with # are compressed with scaling technology.
NOTE:
• Signals other than those specifi ed in the table above may not be displayed correctly. If this should happen, change the re-
fresh rate or resolution on your PC. Refer to Display Properties help section of your PC for procedures.
• UXGA (1600 x 1200) is supported for separate sync signal only.
Horizontal: 15 kHz to 100 kHz (RGB: 24 kHz or over)
Vertical: 50 Hz to 85 Hz
