Page #2 background imageLoading...
Page #2 background image
NEC Display Solutions of America, Inc.
PA521U/PA571W/PA621X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PA521U/ PA571W/PA621X Page 2 of 14
Formulas: 4:3 Aspect Ratio (PA621XXGA)
The Projection Formulas use the image width for calculation. Image width is the same for all aspect ratios, only vertical image size
varies. For proper projector placement, determine the image width for a desired screen size. Use the Screen Formulas below to
calculate all screen dimensions. Plug in the image width for “W” in the Projection Formulas.
Refer to the diagrams and charts for popular screen sizes on page 2 and 3:
Projection Formulas: Definitions: 4:3 Screen Formulas:
NP11FL: C = 0.827W 1.374 W = Image Width W = H x 4/3
NP12ZL: C(Wide) = 1.214W 1.794 ------ C(Tele) = 1.578W 1.794 H = Image Height (size) H = W x 3/4
NP13ZL: C(Wide) = 1.525W 1.974 ------ C(Tele) = 3.043W 1.972 C = Throw distance Diagonal = W x 5/4
NP14ZL: C(Wide) = 3.034W 4.844 ------ C(Tele) = 4.855W 4.844
NP15ZL: C(Wide) = 4.797W 7.630 ------ C(Tele) = 7.291W 7.660
NP30ZL: C(Wide) = 0.827W 1.587 ------ C(Tele) = 1.078W 1.587
Note: Tilting the front of the projector up or down by more than 45° from level could reduce lamp life by up to 20%.
Distance Chart for popular 4:3 screens
Rear Lens
NP11FL
Diagonal
Width(W)
Height (H) 0.8:1
inches inches inches inches
40 32 24 25.09 24.9 - 32.9 37.1 - 48.7 46.8 95.4 92.2 150.5 145.9 225.7
60 48 36 25.09 38.1 - 50.2 56.5 - 74.0 71.2 - 144.1 140.8 228.2 222.6 342.3
67 54 40 25.09 42.7 - 56.2 63.3 - 82.8 79.8 - 161.1 157.8 255.4 249.5 383.1
72 58 43 25.09 46.0 - 60.5 68.1 - 89.1 85.9 - 173.3 169.9 274.8 268.7 412.3
84 67 50 25.09 54.0 - 70.9 79.8 - 104.2 100.5 - 202.5 199.0 - 321.4 314.7 - 482.3
90 72 54 25.09 58.0 - 76.0 85.6 - 111.8 107.8 - 217.1 213.6 - 344.7 337.8 - 517.3
100 80 60 25.09 64.6 - 84.7 95.3 - 124.4 120.0 - 241.5 237.9 - 383.6 376.1 - 575.6
120 96 72 25.09 77.8 - 101.9 114.8 - 149.7 144.4 - 290.2 286.4 - 461.2 452.9 - 692.3
150 120 90 NA 97.7 - 127.8 143.9 - 187.6 181.0 - 363.2 359.2 - 577.8 568.0 - 867.3
180 144 108 NA 117.5 - 153.6 173.0 - 225.4 217.6 - 436.2 432.1 - 694.3 683.1 - 1042.2
210 168 126 NA 137.3 - 179.5 202.2 - 263.3 254.2 - 509.3 504.9 - 810.8 798.3 - 1217.2
240 192 144 NA 157.2 - 205.4 231.3 - 301.2 290.8 - 582.3 577.7 - 927.3 913.4 - 1392.2
270 216 162 NA 177.0 - 231.3 260.4 - 339.1 327.4 - 655.3 650.5 - 1043.8 1028.5 - 1567.2
300 240 180 NA 196.9 - 257.1 289.6 - 376.9 364.0 - 728.3 723.3 - 1160.4 1143.7 - 1742.2
400 320 240 NA 263.1 - 343.4 386.7 - 503.2 486.0 - 971.8 966.0 - 1548.8 1527.4 - 2325.5
500 400 300 NA 329.2 - 429.6 483.8 - 629.4 608.0 1215.2 1208.8 - 1937.2 1911.2 - 2908.7
Screen Size (4:3)
2.97 -4.79:1
NP30ZL
NP12ZL
NP13ZL
NP14ZL
1.50 - 3.02:1
NP15ZL
4.70 - 7.20:1
inches
Zoom Lenses
inches
inches
0.79 - 1.04:1
1.19 - 1.56:1
inches
inches
