NEC PlasmaSync 42XP10

English
English-32
Specifi cations P50XP10
PDP Module Diagonal: 50"/1269 mm
Pixel Pitch 0.81 mm (W)/0.81 mm (H)
Resolution 1365 x 768
Frequency Horizontal ANALOG: 15.625/15.734kHz, 31.0kHz - 108.5kHz
DIGITAL: 15.625/15.734kHz, 31.0kHz - 91.1kHz
Vertical 24Hz to 120.4Hz
Panel Display Size 1106 mm (W) x 622 mm (H)
43.5 in (W) x 24.5 in (H)
Input Signals DVI DVI-D 24pin Digital RGB DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*, 1920X1080*
VGA 15pin Mini D-sub Analog RGB 0.7V p-p, Input Impedance 75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3Vp-p Neg
RGBHV BNC (R,G,B,H,V) Analog RGB 0.7V p-p, Input Impedance 75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3Vp-p Neg.
DVD/HD RCA (Y, Cb/Pb, Cr/Pr) Component Y : 1.0Vp-p/75ohm, Cb/Cr (Pb/Pr) : 0.7Vp-p/75 ohm
HDTV/DVD:1080p*, 1080i*, 720p@50Hz/60Hz,
576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
VIDEO1 BNC Composite 1.0V p-p Input Impedance 75 ohm
NTSC/PAL(B, G, M, N)/SECAM/4.43NTSC/PAL60
VIDEO2 RCA Composite 1.0V p-p Input Impedance 75 ohm
NTSC/PAL(B, G, M, N)/SECAM/4.43NTSC/PAL60
S-VIDEO DIN 4 pin S-VIDEO Y: 1.0Vp-p/75ohm C: 0.286Vp-p/75 ohm(NTSC),
0.3Vp-p/75ohm(PAL/SECAM)
NTSC/PAL(B, G, M, N)/SECAM/4.43NTSC/PAL60
Output Signal (VIDEO1
and VGA can also be used
as OUTPUT terminals)
VGA 15pin Mini D-sub Analog RGB Analog RGB Video: 0.7V p-p with 75 ohm terminated
Separate HV sync: TTL level (Pos / Neg)
VIDEO1 BNC Composite Composite 1.0V p-p with 75 ohm terminated
Audio AUDIO Input RCA (L/R) X3 Analog Audio Stereo L/R 0.5Vrms
Speaker Output External Speaker Jack 8W + 8W (8 ohm)
External Control RS-232C: IN 9 Pin D-sub
RS-232C: OUT 9 Pin D-sub (daisy chain)
Power Supply 6.0-2.6A@100-240V AC, 50/60Hz
Operational Environment Temperature 0˚ to 40˚C / 32˚ F to 104˚ F
Humidity 20% to 80% (without condensation)
Storage Environment Temperature -10˚C to 50˚C / 14˚ F to 122˚F
Humidity 10 - 90% (without condensation)/ 90% - 2% x (Temp - 40°C) regarding over 40°C
Dimensions Net 1221mm(W) x 743mm(H) x 127mm(D) / 48.1"(W) x 29.3"(H) x 5.0"(D)
Gross 1400mm(W) x 980mm(H) x 360mm(D) / 55.1"(W) x 38.6"(H) x 14.2"(D)
We ig ht
(without speaker and stand )
Net 47.5 kg / 104.7 lbs
Gross 57.5 kg / 126.8 lbs
VESA compatible arm
mounting interface
700mm x 300mm 4 Holes (screw M8 Depth 16mm)
Complied Regulatory
and Guidelines
UL 60950-1/CSA C22.2 No.60950-1/EN60950-1/IEC60950-1
FCC-B/DOC-B/EN55022-B/EN55024/EN61000-3-2/EN61000-3-3/CE/C-Tick
Power Management VESA DPM (Separate HV Sync. only)
Plug & Play VESA DDC2B
Accessories Remote control, AA Batteries, Power cord, Users Manual (CD-ROM),
Start Up Guide (Paper / CD-ROM), Main Power Switch cover and screw, Cable clamps
*Compressed Image
