2. Projecting an Image (Basic Operation)

Adjusting the tilt (Tilt foot)

Adjustingtheleftandrighttilt.

1. Remove the spacers.

 Rotatethetiltfootclockwisetoloosenit(leftandright).

• Theprojectorcanbepositionedwiththespacersattached.Keep

the spacer.

2. Rotate the tilt foot to adjust the left and right tilt.

NOTE:

• Donotextendthetiltfootbeyonditsheightlimit(18mm/0.7inches).Doing

somaycausethetiltfoottocomeoutoftheprojector.

• Attachthespacertoeachtiltfootwhenmovingtheprojector.

Finely adjusting the vertical tilt

1. Remove the spacers.

Down

2. Rotate the tilt foot on each side to ﬁnely adjust the height.

NOTE:

• Donotusethetilt-footforpurposesotherthanoriginallyintended.

 Misusessuchasusingthetiltfoottocarryorhang(fromthewallorceiling)

theprojectorcancausedamagetotheprojector.
