113

6. Installation and Connections

Connecting to a Wireless LAN (Optional: NP02LM series)

TheUSBWirelessLANUnitalsoprovidesawirelessLANconnection.TouseawirelessLANconnection,youare

requiredtoassignanIPaddresstotheprojector.

Important:

• IfyouusetheprojectorwiththeUSBWirelessLANUnitintheareawheretheuseofwirelessLANequipmentis

prohibited,removetheUSBWirelessLANUnitfromtheprojector.

• BuytheappropriateUSBWirelessLANUnitforyourcountryorarea.

NOTE:

• ThegreenLEDontheUSBWirelessLANUnitashestoshowthattheUSBWirelessLANUnitisworking.

• Yourcomputer’swirelessLANadapter(orunit)mustbecompliedwithWi-Fi(IEEE802.11b/g/n)standard.

FlowofSettingWirelessLAN

Step 1: AttachtheUSBWirelessLANUnittotheprojector.

Step 2: ConnectthecomputertotheprojectorviawiredLAN.(→ page 112)

 Usethecomputer’sbrowsertodisplaytheprojector’sHTTPserver.(→ page 43)

Step 3: UseanHTTPservertosetthewirelessLAN.(→ page 46)

 AccesstheHTTPserverfunctiontoset[NETWORKSETTINGS]→[SETTINGS]→[WIRELESS]→

[EASYCONNECTION],[PROFILE1]or[PROFILE2].

NOTE:

• TousetheHTTPserverfunction,theprojectormustbeconnectedtoanetwork.

 FirstusethewiredLANtoconnecttheprojectortoanetworkandthenusetheHTTPservertosetthewirelessLAN.

• AftersettingthewirelessLANbyusingtheHTTPserver,set[NETWORKSETTINGS]→[SETTINGS]→[WIRED]→[DISABLE]

WhenswitchingtosetontheprojectorafterconnectingtothewirelessLAN:

UsethemenutosetthewirelessLANconnectionfortheprojector.

(→page97)

Select[DISABLE],[EASYCONNECTION],[PROFILE1]or[PROFILE2]yousetfromtheHTTPserver.

AttachingtheUSBWirelessLANUnit

NOTE:

• TheUSBWirelessLANUnitmustbeinsertedintotheUSBWirelessLANUnitportinthecorrectdirection.Itcannotbeinserted

inthereversedirection.IftheUSBWirelessLANUnitisinsertedinthereversedirectionwithexcessiveforceapplied,theUSB

portmaybreak.

• BeforetouchingtheUSBWirelessLANUnit,touchametallicobject(suchasadoorknoboraluminumwindowframe)todischarge

thestaticelectricityfromyourbody.

• AlwaysinsertorremovetheUSBWirelessLANunitwhenthemainpoweristurnedoff.Failuretodosomaycauseprojector

malfunctionordamagetotheUSBwirelessLANunit.Iftheprojectorwillnotworkcorrectly,turnofftheprojector,disconnect

thepowercord,andthenconnectitagain.

• DonotinsertotherUSBdevicesintotheUSBWirelessLANunitport.DonotinserttheUSBWirelessLANunitintotheUSB(PC)

port(TypeB).
