NEC V230X - Compatible Input Signal List

90
7. Appendix
 Compatible Input Signal List
Horizontal:15KHzto100KHz(RGB:24KHzorover)
Vertical:50Hzto120Hz(Signalswithhigherthanrefreshrate85Hzsupportresolutionsof1024x768orlower.)
AnalogRGB
Signal
Resolution
( dots )
Aspect Ratio
Refresh Rate
(Hz)
VGA 640 × 480 4:3 60/72/75/85/
iMac
SVGA 800 × 600 *
1
4:3 56/60/72/75/85/
iMac
XGA 1024 × 768 *
2
4:3 60/70/75/85/
iMac
WXGA 1280 × 768 15:9 60
1280 × 800 16:10 60
Quad-VGA 1280 × 960 4:3 60
SXGA 1280 × 1024 5:4 60
SXGA+ 1400 × 1050 4:3 60
UXGA 1600 × 1200 4:3 60
MAC13" 640 × 480 4:3 67
MAC16" 832 × 624 4:3 75
MAC19" 1024 × 768 4:3 75
Component
Signal Format Aspect Ratio
Refresh Rate
(Hz)
HDTV (1080i) 1920 × 1080 16:9 50/60
HDTV(720p) 1280 × 720 16:9 50/60
SDTV (480p) 720 × 480 4:3/16:9 60
SDTV(576p) 720 × 576 4:3/16:9 50
CompositeVideo/S-Video
Signal Aspect Ratio
Refresh Rate
(Hz)
NTSC 4:3 60
PAL 4:3 50
PAL60 4:3 60
SECAM 4:3 50
3D
Signal
Resolution
( dots )
Aspect Ratio
Refresh Rate
(Hz)
SVGA 800 × 600 4:3 60*
3
/120
XGA 1024 × 768 4:3 60*
3
/120
1280×720 1280 × 720 16:9 60/120
WXGA 1280 × 800 16:10 60/120*
4
*1NativeresolutiononSVGAmodel(V260/V230)
*2NativeresolutiononXGAmodel(V300X/V260X/V230X
*3Supports[OVER/UNDER]
*4 Reduced Blanking (RB) signal)
NOTE:
• Animagewithhigherorlowerresolutionthantheprojector’snativeresolution(V300X/V260X/V230X:1024×768/V260/V230:
800x600)willbedisplayedwithAdvancedAccuBlend.
• SynconGreenandCompositesyncsignalsarenotsupported.
• Signalsotherthanthosespeciedinthetableabovemaynotbedisplayedcorrectly.Ifthisshouldhappen,changetherefresh
rateorresolutiononyourPC.RefertoDisplayPropertieshelpsectionofyourPCforprocedures.
HDMI
Signal
Resolution
( dots )
Aspect Ratio
Refresh Rate
(Hz)
VGA 640 × 480 4:3 60
SVGA 800 × 600 *
1
4:3 60
XGA 1024 × 768 *
2
4:3 60
WXGA 1280 × 768 15:9 60
1280 × 800 16:10 60
Quad-VGA 1280 × 960 4:3 60
SXGA 1280 × 1024 5:4 60
SXGA+ 1400 × 1050 4:3 60
HDTV (1080i) 1920 × 1080 16:9 50/60
HDTV(720p) 1280 × 720 16:9 50/60
SDTV (480p) 720 × 480 4:3/16:9 60
SDTV(576p) 720 × 576 4:3/16:9 50
