NEC VT480 - Cabinet Dimensions

NEC Solutions (America), Inc.
Visual Systems Division
VT480/58/580 Installation Guide
Ceiling Mounted and Desktop Rev 1.1eu
www.visualsystems.com VT480/58/580 Page 3 of 6
Cabinet Dimensions
The following drawings show the cabinet dimensions.
Dimensions are in inches. For millimeters multiply by 25.4.
MENU
SELECT
EN
T
ER
EXI
T
ON/STAND BY
SOURCE AUTO ADJ.
POWER
STATUS
LAMP
VT 480
PUSH
10.17
12.07
0.10
2.57
2.22
3.27
4.45
Ventilation
Ventilation
4.76
2.78
2.29
7.41
0.07
2.26
Zoom Lever
Focus lever
Ventilation
