Necchi K121A - Inserting the Bobbin

10
Inserting the bobbin
n
Attention
Turn the power switch to off ("O").
When inserting or removing the bobbin,
the needle must be fully raised.
Remove the sewing table, then open the
hinged cover.
1
Hinged cover
1
3
2
1
4
Pull the bobbin case by the hinged latch.
Remove the bobbin of the bobbin case.
1
Hinged latch
Hold the bobbin case with one hand. Insert
the bobbin so that the thread runs in a
clockwise direction (arrow).
Pull the thread from the slot under the tension
spring and through the opening. Leave a
10cm tail of thread.
1
Slot
2
Tension spring
3
Opening
4
10cm
Hold the bobbin case by the hinged latch.
Make sure the bobbin case nger ts into
the notch at the top of the race as shown in.
Close the hinged cover.
1
Hinged latch
2
Bobbin case nger
3
Notch
Note
If the bobbin case is not properly placed
back into the machine, it will fall out form
the shuttle immediately after starting to
sew.
1
3
2
1
