8
Winding the bobbin
Please following the number order and see the corresponding illustrations below.
1. Place the thread and spool holder onto
the spool pin. For better sewing quality,
choose a proper size of the spool holder
for the thread and attach it next to the
spool.
①
Large spool holder
②
Small spool holder
2. Draw the thread from the spool and place
the thread in between the upper thread
guide.
4. Place the thread end through one of
the inner holes as illustrated and place
the empty bobbin on the bobbin winder
spindle. Then align the notch with bobbin
winder spindle spring.
①
Notch
②
Bobbin winder spindle spring
5. Push the bobbin to the right. When the
bobbin winder spindle is pushed to the
right, the screen will display the gure.
3. Wind the thread clockwise around the
tension discs.
2
1
2
1
To Next Page
