Nedap PowerRouter PR30S User Manual

48
AC / ENERGY MANAGER MODULE
PR50S PR37S PR30S
AC Input Range 180 - 254 Vac 45 - 55 Hz *
Output Voltage in UPS / Inverter / Grid mode 230 VAC ±2% true sine wave <5% THD
Frequency 50 Hz ±0.2%
Continuous Output Power at 40
o
C (P nom) 5000 VA 3700 VA 3000 VA
Output Peak Power (5 seconds) 2 x P nom
Max. Efciency 94%
Standby Power Consumption 6 W
Protection electronic, fused
Switch Over Time 20 milliseconds
2 Relais (user programmable) NO / NC (250 V, 1 A / 24 Vdc, 5 A)
Display integrated, 4 x 20 characters
Connectivity TCP/IP
* Limited by local anti-islanding requirements
SOLAR MODULE
Solar Voltage 150 - 600 Vdc
MPP Voltage 100 - 450 Vdc
Max. Input 5.5 kWp (2 x
15A)
4 kWp (2 x
15A)
3.3 kWp (1 x
15A)
MPP Efciency > 99.9%
Galvanic Separation Yes
DC Disconnection Yes, optional
Anti Islanding Protection VDE 0126.1.1, G83/1(UK),
RD1663/2000(ESP),
others countries on request
