Nedap Smart Deactivator User Manual

10
Copyright © by N.V. Nederlandsche Apparatenfabriek NEDAP. No part of this drawing
may be reproduced or distributed in any form or by any means, or stored in a data base or
retrieval system without the prior written permission of NEDAP.
description:
quick ref. Smart Deactivator | art. no. 9200002
doc. article no: 5276802
chk:
drw: CB 2013/05/29
sheet: 45.01 of 1
drawing: T9937-676
1x Smart Deactivator including power supply
Smart Deactivator
1x Antenna connector set
05
Beeper sound volume
04
Connect to power 100-240V
deactivation
detection
06
Beeper sound (Standard mode)
56
40.5
25
175.3
106
14.5
86.6
131.6
10
4.5
109.8
01
ANT Antenna wire 2
GND Ground
GND Ground
ANT Antenna wire 1
Tie Wrap
to deactivator
antenna
ANT1
ANT2
02
Connect deactivator antenna to antenna
connector
Mount housing to solid surface
03
Connect deactivator antenna to Smart
Deactivator
1x Connector cover1x Power Supply
Rev. : B.03
GROENLO - HOLLAND

Nedap Smart Deactivator Specifications

General

Brand	Nedap
Model	Smart Deactivator
Category	Controller
Language	English
