Nederman FX2 Original - 3.3 Dimensions duct connections; 3.4 Technical data; 3.5 Material specification

FX
2
Original/Chem
files made of anodized aluminium with a white elec-
trophoretic deposition coating for fume extraction in
aggressive environments where there must be resist-
ance from corrosion.
3.3Dimensions duct connections
See Figure1.
3.4Technical data
FX
2
Original/Chem D50 arms D75 arms D100 arms
Diameter 50 mm 75 mm 100 mm
Weight, Up/Down - Low 1,9 - 2,8 kg (4.2 - 6.2
lbs)
3,3 - 3,5 kg (7.3 -
7.7 lbs)
4,8 - 6,9 kg (10.6 - 15.2 lbs)
Weight, Up - Plus 2,5 - 3,4 kg (5.5 - 7.5
lbs)
4,1 - 4,3 kg (9.0 -
9.5 lbs)
5,2 - 7,9 kg (11.5 - 17.4 lbs)
Weight, Up/Down - Through 1,9 - 2,8 kg (4.2 - 6.2
lbs)
3,3 - 3,5 kg (7.3 -
7.7 lbs)
4,8 - 5,9 kg (10.6 - 13.0 lbs)
Recommended airflow 50 - 110 m/h (29.4 -
64.7 cfm)
110 - 240 m/
h (64.7 - 140.3
cfm)
200 - 450 m/h (117.7 -
264.9 cfm)
Maximum airflow 142 m/h (83.6 cfm) 318 m/h (187.2
cfm)
565 m/h (332.6 cfm)
Maximum vacuum 3500 Pa (0.51 psi) 3500 Pa (0.51
psi)
3500 Pa (0.51 psi)
Ambient temperature (extrac-
ted air)
Max 70°C (158°F) Max 70°C
(158°F)
Max 70°C (158°F)
Material recovery 99% by weight 99% by weight 99% by weight
3.5Material specification
See Figure2.
FX
2
Original FX
2
Chem
1 PP plastic
2 Anodized aluminium
3 PP plastic
4 Rubber: EPDM rubber
5 Painted aluminium
6 Anodized aluminium
7 PP plastic
8 Spring: Stainless steel
9 Damper: PP/TPE
10 PP plastic
11 Axle: Stainless steel
1 PP plastic
2 Anodized aluminium with white electrophoretic deposition coating
3 PP plastic
4 Rubber: EPDM rubber
5 Painted aluminium
6 Anodized aluminium with white electrophoretic deposition coating
7 PP plastic
8 Spring: Stainless steel
9 Damper: PP/TPE
10 PP plastic
11 Axle: Stainless steel
