EasyManuals Logo

Neets echo plus Installation Manual

Neets echo plus
13 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #5 background imageLoading...
Page #5 background image
Page 5 of 13
Description
EcHo Plus is a compact yet surprisingly intelligent AV control system. It is remarkably simple to
use, thanks to an intuitive graphical interface with a minimum number of buttons.
With EcHo Plus anyone can start up a presentation without complicated procedures.
Simply press ONE button and you are ready to begin!
EcHo Plus is a perfect choice for the classroom, meeting or conference room and is easy to
install. EcHo Plus can control devices through IR, RS232 or even LAN. EcHo Plus is available in
polar white.
The drawings in the manual of Neets Control - EcHo Plus is based on the DK, US and EU versions.
Function description
RS-232 (Tx+Rx) 1
RS-232 (Tx) or IR (controls up to 2 IR devices) 1
LAN device control 2
I/O 3
Buttons 8
NEB Bus 1 (2 NEB)
USB port for conguration 1
PIR sensor input Ye s
Light on/off Ye s
Room darkening Ye s
Screen up/down Ye s
Volume control Ye s
Device feedback Ye s

Table of Contents

Other manuals for Neets echo plus

Preview: User Manual
User Manual12 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Neets echo plus and is the answer not in the manual?

Neets echo plus Specifications

EcHo Plus EU

Power IconPower
input voltage12 VDC
power usage1 W
power adaptor input voltage100 VAC – 240 VAC
line frequency50 Hz – 60 Hz
max power usageMax 8 W
Ports & Interfaces IconPorts & Interfaces
RS-232 port count1 x bi-directional
RS-232 port baud rate1200 – 115200 bit/sec
RS-232 port data bits7, 8
RS-232 port parityEven, Odd, None
RS-232 port stop bits1, 2
RS-232 port connector3 pin screw block
RS-232 or IR port count1 x uni-directional
RS-232 or IR port baud rate1200 – 115200 bit/sec
RS-232 or IR port data bits7, 8
RS-232 or IR port parityEven, Odd, None
RS-232 or IR port stop bits1, 2
RS-232 or IR port IR frequency400 Hz to 500 KHz
RS-232 or IR port connector2 pin screw block
Network speed10 / 100 Mbit
Network duplex modesHalf or Full
Network DHCPDefault off
Network default IP192.168.254.252
Network default gateway192.168.1.1
Network default subnet mask255.255.255.0
Operating Environment IconOperating Environment
storage temperature-20 °C to 50 °C
operation temperature0 °C to 30 °C
storage moistureNon-condensing
operation moistureNon-condensing
Weight and Dimensions IconWeight and Dimensions
width55 mm
height55 mm
depth17 mm
weight90 g
shipping weight0.3 kg
shipping dimension155x85x55 mm

EcHo Plus DK

Power IconPower
input voltage12 VDC
power usage1 W
power adaptor input voltage100 VAC – 240 VAC
line frequency50 Hz – 60 Hz
max power usageMax 8 W
Ports & Interfaces IconPorts & Interfaces
RS-232 port count1 x bi-directional
RS-232 port baud rate1200 – 115200 bit/sec
RS-232 port data bits7, 8
RS-232 port parityEven, Odd, None
RS-232 port stop bits1, 2
RS-232 port connector3 pin screw block
RS-232 or IR port count1 x uni-directional
RS-232 or IR port baud rate1200 – 115200 bit/sec
RS-232 or IR port data bits7, 8
RS-232 or IR port parityEven, Odd, None
RS-232 or IR port stop bits1, 2
RS-232 or IR port IR frequency400 Hz to 500 KHz
RS-232 or IR port connector2 pin screw block
Network speed10 / 100 Mbit
Network duplex modesHalf or Full
Network DHCPDefault off
Network default IP192.168.254.252
Network default gateway192.168.1.1
Network default subnet mask255.255.255.0
Operating Environment IconOperating Environment
storage temperature-20 °C to 50 °C
operation temperature0 °C to 30 °C
storage moistureNon-condensing
operation moistureNon-condensing
Weight and Dimensions IconWeight and Dimensions
width45 mm
height72 mm
depth17 mm
weight90 g
shipping weight0.3 kg
shipping dimension155x85x55 mm

EcHo Plus US

Power IconPower
input voltage12 VDC
power usage1 W
power adaptor input voltage100 VAC – 240 VAC
line frequency50 Hz – 60 Hz
max power usageMax 8 W
Ports & Interfaces IconPorts & Interfaces
RS-232 port count1 x bi-directional
RS-232 port baud rate1200 – 115200 bit/sec
RS-232 port data bits7, 8
RS-232 port parityEven, Odd, None
RS-232 port stop bits1, 2
RS-232 port connector3 pin screw block
RS-232 or IR port count1 x uni-directional
RS-232 or IR port baud rate1200 – 115200 bit/sec
RS-232 or IR port data bits7, 8
RS-232 or IR port parityEven, Odd, None
RS-232 or IR port stop bits1, 2
RS-232 or IR port IR frequency400 Hz to 500 KHz
RS-232 or IR port connector2 pin screw block
Network speed10 / 100 Mbit
Network duplex modesHalf or Full
Network DHCPDefault off
Network default IP192.168.254.252
Network default gateway192.168.1.1
Network default subnet mask255.255.255.0
Operating Environment IconOperating Environment
storage temperature-20 °C to 50 °C
operation temperature0 °C to 30 °C
storage moistureNon-condensing
operation moistureNon-condensing
Weight and Dimensions IconWeight and Dimensions
width45 mm
height105 mm
depth24 mm
weight90 g
shipping weight0.3 kg
shipping dimension150x170x55 mm
View in Manual
