Appliance door en
21
Attaching the rails
The rails only fit on the right or the left side. For both
rails, ensure that the curved rods are at the front.
1. First, insert the rail in the middle of the rear socket ‚,
until the rail rests against the cooking compartment
wall, and push it back ƒ (figure !).
2. Then insert the rail into the front socket „, until the
rail also rests against the cooking compartment wall
here, and press it downwards … (figure ").
qAppliance door
Ap p l i a n c e door
With good care and cleaning, your appliance will retain
its appearance and remain fully functional for a long
time to come. This will tell you how to remove the
appliance door and clean it.
Removing and fitting the appliance door
To clean the door panels, you can detach the appliance
door.
:Warning – Risk of injury!
The hinges of the appliance door may snap shut with
great force. Always fully turn the two locks for fitting and
removing the appliance door.
:Warning – Risk of injury!
If the appliance door has been removed without turning
both locking levers to their limit stops, the hinge may
snap shut. Do not reach into the hinge. Call the after
sales service.
Detaching the appliance door
1. Open the left- and right-hand door locks (fig. !).
To do this, hold the screwdriver horizontally and use
it to slide the door lock (black component) on each
side of the door all the way up (fig. ").
Tip: Use a torch to light up the gap so that you can
see the door locks.
Door lock closed (fig. #)
Door lock open (fig. $)
2
F
G
1
D
E
2I
1I
I
I
