PROGRAMMING INSTRUCTIONS
NOTE: The MODE dial must be in the PROGRAM position to set a schedule.
The LCD will display the currently scheduled program (default is all WATER DAYS.) The
SELECT keys will scroll the LCD display through each of the scheduling positions
WATER DAYS, ODD, EVEN, INTERVAL, and INTERVAL START DATE. Be sure the
PROGRAM dial is set on the program you want to change (A, B, or C) and that you want to
change the current schedule. A scheduling option is chosen after you press a button, either
SELECT or ADJUST. The old schedule is replaced with the new one. It’s easy to program a
schedule with the following procedures.
Set Water Days Scheduling Option
Turn the large dial to the SCHEDULE position. Use the SELECT till the raindrops appear
above the days of the week. Press the ADJUST button to select that day for watering or
press ADJUST for non-watering days. A flashing indicator appears over the day you’re
about to set. Raindrops appear over selected days to water. The indicator automatically
moves one day to the right after an ADJUST or key press. Continue selecting or
deselecting the days you want the controller to water until you have your 7-day calendar set.
NOTE: Programming a WATER DAYS schedule deletes any other schedule for the
selected program.
Set Odd/Even Day Scheduling Option
Turn the large dial to the SCHEDULE position. The last scheduling option chosen for the
current program appears on the LCD. To set either an ODD or an EVEN schedule press the
SELECT button till an arrow appears on the LCD next to the appropriate schedule (ODD
or EVEN). A DATE must be set for odd/even watering). The SELECT buttons act as toggle
keys and will toggle between odd or even.
NOTE: Programming an ODD/EVEN schedule deletes any other schedule for the
selected program.
16
