Nelson INTRA 2100 User Manual

1 Introduction Page 11
Stud welding units Operating manual Date: July 2021
INTRA 2100/1400 07.2021 / EN Rev.: A
1.5.2 INTRA 1400 technical data
Max. weld diameter - Drawn arc
- Short cycle
16mm
9mm
Weld current, continuously adjustable
Current reserve for weld Ø
(measured with standard equipment on a stable network)
200 – 1400 A
Welding output in continuous operation
(drawn arc, with standard equipment)
Stud Weld Ø
Welding
sequence
S 16 16.0mm 6 units/min
MP 16 14.6mm 8 units/min
MR 16 13.2mm 10 units/min
S 10 10.0mm
∞
Weld time, continuously adjustable - Drawn arc
- Short cycle
0.1 s – 1 s
0.01 s – 0.1 s
Dimensions width
Height
Depth
Weight
520mm
750mm
770mm
190 kg
Connection voltage 50/60 Hz – Standard
(options upon request)
Nominal power
Network protection per phase (at 400 V)
Connected load
Protection type
CEE power plug (at 400 V)
3 ~ 400 V
25 kVA
63 A
51.8 kVA
IP 23
63 A (3L+PE)
Cooling type External cooling (fan installed)
Operating temperature 0°C to +40°C
Storage temperature -25°C to +55°C
Relative humidity
0% to 50% at 40°C
0% to 90% at 20°C
