51
ENGLISH
10.3 Other general specifications
10.4 Document specifications
Noise level <70 sBA (68 dBa)
Operating temperature 10°C - 40°C
Power requirements 230V/50Hz (voltage tolerance: +10%/-10%)
115V/60Hz (voltage tolerance: +6%/-10%)
100V/50Hz (voltage tolerance: +6%/-10%)
Weight Whole system: 69 kg (152 lbs)
Paper Quality minimum 60 gr/m² (15 lb bond)
maximum 250 gr/m² (62.5 lb bond), when folded max. 170
gr/m² (42.5 lb bond)
Booklets up to approximately 1 mm (0.04 inch) thickness,
depending on stiffness
Paper size Minimum width: 130 mm (5.1")
Maximum width: 236 mm (9.3"), when folded max. 230
mm (9.1")
Minimum length: 90 mm (3,5"), the minimum document
length used for the upper feeder is 115 mm (4.5")
Maximum length: 356 mm (14")
Folding capacity max. 5 sheets (max. 80 gr/m²)
Envelope sizes Standard BRE (Business Reply Envelopes)
Envelope Quality minimum 80 gr/m² (20 lb bond)
maximum120 gr/m² (30 lb bond)
