6 Additional Information
6-2
Number of Pulses
0-20
Polarity Switching
On: With polarity switching, OFF: Without polarity switching
Capacitance
2,160µF

Output Measurements
Voltage
Poring Pulse
1,000 - 3,276V (increment: 1V)
0.0 - 999.9V (increment: 1V)
Transfer Pulse
0.0 - 327.6V (increment: 0.1V)
Current
Poring Pulse
10.00 - 99.99A (increment: 0.01A)
0.000 - 9.999A (increment: 0.001A)
Transfer Pulse
10.00 - 55.99A (increment: 0.01A)
0.000 - 9.999A (increment: 0.001A)
Energy
Poring Pulse
1,000 - 9,999J (increment: 1J)
100.0 - 999.9J (increment: 0.1J)
10.00 - 99.99J (increment: 0.01J)
0.000 - 9.999J (increment: 0.001J)
*Joule(J) = Voltage x Ampere x Pulse length x Numbers of Pulses
Transfer Pulse
1,000 - 9,999J (increment: 1J)
100.0 - 999.9J (increment: 0.1J)
10.00 - 99.99J (increment: 0.01J)
0.000 - 9.999J (increment: 0.001J)
*Joule(J) = Voltage x Ampere x Pulse length x Numbers of Pulses

Others
Impedance Measurement
10.00k - 30.00kΩ (increment: 0.01kΩ)
0.030k - 9.999kΩ (increment: 0.001kΩ)
Memory
99 Programs
Pulse Current Limit Mode
Over the current automatically shuts down, > 50A
Sample Resistance
30Ω minimum at 300V
Input Rating
AC100-240V 50/60Hz
Operating Environment
Temperature: 5-40℃,
Humidity: 85%RH Max (Non-condensing)
Dimensions
432(W) x 336(D) x 136(H) mm
Weight
8.7kg
