NESPACE48/3K Operation Manual
KE NESPACE KA Rectifier Control Unit Operation Manual English R 2016_07 V1_1
20 /21
backplane connector.
4) Carefully push in the ejector handle to lock the mating connectors. The ejector
handle should easily snap into place and lock into the Rectifier Module front panel.
5) Check that the module operates normally and that no alarms are activated.
Definitions
C/B : Circuit Breaker
S/W : SWitch
RMS : Root Mean Square
LVD : Low Voltage Disconnect
ACF : AC Fail(power failure)
ACV : AC Voltage
ALM : ALarM
AMP : AMPere
AUTO-FL MODE : AUTO-FLoating charging MODE
AUTO-EQ MODE : AUTO-EQualize charging MODE
DCV : DC Voltage
Comm. Fail : Communication Fail
Comp. : Compensation
Curr. : Current
DC : Direct Current
DCF : DC Fail
DCOV : DC Over Voltage
DCUV : DC Under Voltage
DCH : DisCHarge
FF : Fan Fail
LCD : Liquid Crystal Display
LED : Light Emitting Diode
LDA : output LoaD Ampere
MF : Module Fail
OV : Over Voltage
OCA : Over Current Ampare
OT : Over Temperature
REC : RECtifier
RX : Receipt channel
TX : Transmit channel
Temp : Temperature
UV : Under Voltage
V1.0 : Version 1.0
ERR : ERRor
ENT : ENTer
LCA : Load Current Ampere
