1.2.2 Input Surge Voltage
✓ Voltage: 6kV (1.2 ×50 ㎲); Current: 3kA (8 × 20 ㎲)
1.2.3 Withstand Voltage
1) Input to Output: 3.0kVac (1 minute) or 4242Vdc (1 minute)
2) Input to Chassis: 1.5kVac (1 minute) or 2121Vdc (1 minute)
1.3 Environmental Characteristics
✓ Pollution Degree 2
✓ Altitude tested to < 2000 meters
✓ 3KW Max Power Range: -35°C ~ +45°C
✓ Full Power to -40°C (Cold Shutdown/Auto-recovery -35°C)
✓ Derated Power ro +75°C (Hot Shutdown/Auto-recovery +65°C)
1.3.1 Cooling
✓ Intelligent Fan control
✓ Front-to-back airflow
1.4 Operating Humidity: 10% ~95%. non-condensing
1.5 Acoustic Noise:
✓ < 60dBA (220Vac, full load, Ta > +40°C)
1.6 Physical Specifications
1.6.1 Dimensions (W x D x H):
✓ 108.2mm x 321.7mm x 41.0mm (4.26in. x 12.67in. x 1.61in.)
1.6.2 Weight:
✓ 2.30 kg (5.07 lbs)
1.7 Safety Reports:
✓ UL Report # E166582-A62-UL
✓ (UL-60950-1, 2
nd
Edition (UL Recognized)
✓ CAN/CSA C22.2 No. 60950-1-07, 2
nd
Edition
✓ EN60950-1:2006/A11:2009/A1:2010/A12:2011/A2:2013
✓ Tests conducted under CB Scheme, issued by UL International Demko A/S,
CB Certificate Number DK-56640-UL (Test Report Ref. No. C16O043-
A0C0 issue date 7-25-2016).
