Net Optics 10/100/1000 Bypass User Manual

8
10/100/1000 Bypass Switch with Heartbeat
The following commands are listed:
a = Input Timeouts
b = Input Configuration
c = Input Heartbeat Packet
d = Display Configuration
e = Display Heartbeat Packet
z = Reset to Factory Defaults
To set the timeout values:
1. Type
a and press Enter to set the timeout values.
2. At the
input time out period prompt, enter the number of
seconds between each heartbeat (1-254 seconds). Press Enter.
3. At the
input retry count prompt, enter the number of missed
heartbeats allowed before the switch enters Bypass ON mode (1-254).
The input retry count must be greater than or equal to the input timeout.
Press Enter.
Note: ________________________________________________________________
Manufacturing default for Input Timeout Period and Input Retry Count are set
to 1 and 3 respectively.
______________________________________________________________________
To set the communications parameters:
1. Type
b and press Enter.
2. At the
Auto neg on/off prompt, type 1 to turn on or 0 to turn off
auto-negotiation.
3. At the
1 Gig on/off prompt, type 1 to turn on or 0 to turn off 1 Giga-
Bit line speed.
4. At the
100 Mbs on/off prompt, type 1 to turn on or 0 to turn off 100
Mbps line speed.
5. At the
10 Mbs on/off prompt, type 1 to turn on or 0 to turn off 10
Mbps line speed.
6. At the
Full Duplex on/off prompt, type 1 to turn on or 0 to turn off
full duplex.
