Net Optics 10/100/1000 Bypass User Manual

10
10/100/1000 Bypass Switch with Heartbeat
duplex full
LFD on
Bypass Detect on
Bypass Disabled
To display the current packet:
1. Type
e and press Enter. The packet is displayed as shown in the example
below.
packet length = 78
MAC DA 00 50 c2 3c 60 00
MAC SA 00 50 c2 3c 60 01
Packet Type 08 00
45 00 00 3c 18 d2 00 00
80 01 0a ff 0a 02 01 dc
0a 01 01 12 08 00 37 5c
02 00 14 00 61 62 63 64
65 66 67 68 69 6a 6b 6c
6d 6e 6f 70 71 72 73 74
75 76 77 61 62 63 64 65
66 67 68 69
CRC bb 8e 1c a9
To restore the bypass switch to factory defaults:
1. Type
z and press Enter. You are prompted to select which type of packet
you want to restore, IP or IPX.
2. Select 1 to restore defaults with an IP packet or 0 to restore defaults with
an IPX packet.
The bypass switch will be reset to the following defaults:
Input Timeout Period: 1
Input Retry Count: 3
Port Speed Gigabit
Full Duplex
LFD: On
Bypass Detect: On
Heartbeat Packet: IPX
