Net Optics 10/100/1000 Bypass User Manual

13
10/100/1000 Bypass Switch with Heartbeat
Specications
Environment
Operating Temperature: 0˚C to 55˚C
Storage Temperature: -10˚C to 70˚C
Relative Humidity: 10% min, 95% max, non condensing
Mechanical
Dimensions: 1.125” high x 10” deep x 6.5” wide
Power
Power Supply Input: 100-240V, 0.5A, 47-63Hz
Power Supply Output: 12V, 3A
Cable Interface
Copper Cable Type: 22-24 AWG unshielded twisted pair cable,
CAT5/CAT5E
Link Distance Supported: 100 meters
Connectors
(2) RJ45, 8-pin connectors (monitoring ports)
(2) RJ45, 8-pin connectors (network ports)
Certications
Fully RoHS compliant
