DRX 3200 / 3210 PROFESSIONAL SATELLITE RECEIVER
8
LNB SETTINGS
Select LNB settings submenu from the Installation menu. Select LNB type as Universal,
Standard or C-Band. Low Band, High Band local oscillator frequencies, 22KHz and DiSEqC
signals and Power setting can be made on the LNB settings menu.
* L o w B a n d 9 . 7 5
H i g h B a n d 1 0 . 6 0
* H i g h B a n d 1 0 . 6 0
2 2 k H z A u t o
Note: For Universal LNB, Low band is 9.75 GHz, High Band is 10.60 GHz. and 22 KHz is Auto.
Standard LNB frequency is 10.00 GHz., C- Band LNB frequency is 5.15 GHz.
They can be changed manually.
ALARM SETTINGS
Select Alarm Settings submenu from the Installation menu. If V. Pattern is set to Yes, video
pattern is displayed during alarm. The alarm condition can depend on Signal, Video and Audio
if any of them is selected as Yes and fails in the operation then the alarm is triggered. In the
following example alarm is triggered only when the signal is gone video and audio do not trigger
alarm. Alarm condition is marked with flashing red LED.
Note: If V. Pattern and No Signal is set to On at the same time, test pattern will be displayed,
“No Signal” message will not be displayed while signal cutoffs.
* V . P a t t e r n Y e s
S i g n a l Y e s
* V i d e o N o
A u d i o N o
LANGUAGE SETTINGS
Select Language submenu from the Installation menu, this menu displays available
languages.
* L a n g u a g e E n g l i s h
CONTROLLING SOFTWARE VERSION NUMBER
Select Info submenu from the Installation menu. Info menu displays information of the device
software. E.g,
0 5 0 4 0 7 v 1 . 3 3
RESETTING THE DEVICE SETTINGS
If you want to reset settings, you can use the Reset Setting submenu. Following screen will be
displayed.
A r e y o u s u r e ?
O K - Y e s M E N U - E x i t
If you press “OK” button, all settings will be set to factory default values.
