DRX 3200 / 3210 PROFESSIONAL SATELLITE RECEIVER
5
♦ Frequency Range Tuner lock frequency range (1MHz, 2MHz, 3MHz, 4MHz,
Auto)
♦ Data Status: On or Off
PID: Data PID
Format: Data collection format
♦ ASI Settings ASI output format setting, Burst or Byte mode is supported.
On or Off.
♦ Ethernet IP Address: Network communicating parameter
Subnet Mask: Network communicating parameter
Gateway Address: Network communicating parameter
Port No: Network communicating port
DHCP: Determining option of the network parameters
automatically
CI
♦ Common Interface CAM module definition is displayed.
Note: These menu configurations will change depend on the product. Because some features
are device specific. There is some detailed information for the menu features below and device
specific menu options are explained with the device model name
USING OFD MENU
Press “MENU” button, the main menu (Parameters, PID, TP Search, Audio Tracks, BISS
Setup (optional), DVB Subtitle (optional) and Installation) is displayed.
You can move the cursor (*) by using “▲”/“▼” buttons. Press “OK” button for sub menu
selection. If you want to change any value, use “◄”/“►” buttons. To change any numerical
value, press “OK” button and change the numeric value at the cursor location by using “◄”/“►”
buttons. Press “OK” button to move the cursor to right by one digit.
As you exit from menus, changes are stored automatically.
CHANGING PROGRAM SETTINGS
If you want to change the program settings (Channel name, Frequency, Polarity, Symbol rate),
go to Parameters submenu.
PARAMETERS
Channel name
Press “OK” button, then a cursor will be displayed. Use “OK” button to move the cursor. You
can change the character over the cursor by using “◄”/“►” buttons. Press “MENU” button to
confirm the entrance.
* C h n E u r o n e w s
F r e q . 1 1 0 5 0
Frequency, Polarity and Symbol Rate
By using this menu, you can set frequency, polarity and symbol rate values.
C h n E u r o n e w s
* F r e q . 1 1 0 5 0
* P o l a r i t y H o r
S . R a t e 2 7 5 0 0
To Next Page
