DRX 3200 / 3210 PROFESSIONAL SATELLITE RECEIVER
9
DYNAMIC PMT
Select Dynamic PMT submenu from the Installation menu. If Dynamic PMT is set to On,
device will trace the PMT data continuously and if PID’s are changed it will set new PID’s
automatically.
* D y n a m i c P M T O n
SETTING BAUD RATE
Select Baudrate submenu from the Installation menu. Set RS232 data transfer rate to a
suitable value. (9600, 19200, 38400, 57600,115200 bps)
* B a u d R a t e 1 1 5 2 0 0
SETTING FREQUENCY RANGE
Select Frequency Range submenu from the Installation menu. Set tuner lock frequency range
to a suitable value. (1MHz, 2MHz, 3MHz, 4MHz, Auto)
* R a n g e A u t o
DATA (DRX 3200 DS)
Select Data submenu from the Installation menu. There are some setting options. With Status
adjustment Data feature can be enabled by switching to On position or disabled by Off position.
* S t a t u s O n
P I D 3 8
* F o r m a t S t r e a m 1
PID setting is used to enter the PID value of the packets that carry the data information.
Format setting is used to setup the data collection procedure from the packets whose PID is
matched with the PID setting. The available options are Transport, PES, Stream1 and
Stream2. For these data collection setting, use the appropriate selection.
ASI SETTINGS (DRX 3200/3210 A, DRX 3200/3210 A CI)
In this mode data output format is burst of data packets (contiguous 188 bytes for each TS
packet).
* B u r s t O n
In this mode burst is off having stuffing between data bytes.
* B u r s t O f f
CI COMMON INTERFACE (DRX 3200/3210 CI, DRX 3200/3210 A CI)
In this menu setting, if there is not any CAM module inserted, you will see “Empty Slot”
message. Depending on the used CAM module, the recognition time will be around 20s. After
the recognition of CAM module you will see the module identification.
