NETAFLEX™ 3G INSTALLATION MANUAL
15
ON-SITE PREPARATIONS
CAUTION
After completion of the hydraulic infrastructure, before the installation of the NetaFlex™ 3G, rinse
the hydraulic infrastructure and fertilizer/acid lines and tanks by running water through them in
order to wash away any residues (chips, shavings, sawdust) due to the setup work.
Electrical preparation
Mains connection
CAUTION
Only qualified electricians are permitted to perform electrical installations!
ATTENTION
Make sure the electrical supply capacity is in accordance with the electrical characteristics of
the NetaFlex™ 3G.
Make sure the short-timed higher current consumption when starting up the system pump was
taken in consideration (for further details see the enclosed Pump Documentation).
The following components have to be provided in the installation:
• A readily accessible circuit breaker, rated according to the NetaFlex™ 3G's total rated power for peak
demand, certified as a branch circuit over current protector (see System Pump List, page 28),
compliant with the national code and requirements.
• Grounding connection: ≤ 10 Ω.
For the selection of the supply wire size - consider (see System Pump List, page 28):
• The NetaFlex™ 3G's total rated power.
• Whether the electricity supply is single-phase or three-phase.
Mains wire size for three-phase system*
5 wires: GND, N, L1, L2, L3
Power source required (kWatt)
3 X 200-250 VAC 3 X 400-480 VAC
Up to 1.5
≥ 2.5 mm
2
(≤ 13 awg)
≥ 2.5 mm
2
(≤ 13 awg)
1.5-2
2-3
3-4 ≥ 4 mm
2
(≤ 11 awg)
4-6 ≥ 6 mm
2
(≤ 9 awg)
6-8
≥ 10 mm
2
(≤ 7 awg)
≥ 4 mm
2
(≤ 11 awg)
8-10 ≥ 6 mm
2
(≤ 9 awg)
10 -12 ≥ 16 mm
2
(≤ 5 awg)
≥ 10 mm
2
(≤ 7 awg)
12-16 ≥ 25 mm
2
(≤ 3 awg)
*Using a cable not longer than 25 meter (82 feet) between the power supply
and the switchboard of the NetaFlex™ 3G.
