◦ mem is system memory.
◦
nic is a Network Interface Card not connected to a network.
◦
nvram is nonvolatile RAM.
◦
nvmem is a hybrid of NVRAM and system memory.
◦
sas is a Serial Attached SCSI device not connected to a disk shelf.
◦
serviceproc is the Service Processor.
◦
storage is an ATA, FC-AL, or SAS interface that has an attached disk shelf.
◦
toe is a TCP Offload Engine, a type of NIC.
5. Run all the default selected diagnostic tests on your storage system by entering the following command:
sldiag device run
6.
View the status of the test by entering the following command:
sldiag device status
Your storage system provides the following output while the tests are still running:
There are still test(s) being processed.
After all the tests are complete, the following response appears by default:
*> <SLDIAG:_ALL_TESTS_COMPLETED>
7. Verify that there are no hardware problems on your new storage system by entering the following
command:
sldiag device status -long -state failed
The following example shows how the full status of the failures is displayed in a test run without the
appropriate hardware:
*> **sldiag device status -long -state failed**
TEST START ------------------------------------------
DEVTYPE: nvram_ib
NAME: external loopback test
START DATE: Sat Jan 3 23:10:55 GMT 2009
STATUS: Completed
ib3a: could not set loopback mode, test failed
END DATE: Sat Jan 3 23:11:04 GMT 2009
LOOP: 1/1
TEST END --------------------------------------------
TEST START ------------------------------------------
DEVTYPE: fcal
1442
