Door grounding cable
Door top hinge
Hinge pin
Make sure that you set the removed doors in a safe place so that they are not accidently damaged.
4. Remove the rear door whose hinges are on the edge where the cabinets meet:
a. Unlock and open the rear door that you are removing.
b. Lift the top hinge pin until it clears the bottom of the hinge.
c. Gently tip the top of the door away from the system cabinet frame, and then release the hinge pin.
d. Lift the door off the bottom hinge, and then set the door aside.
1471
