d. Align the two raised buttons on each side of the drive carrier with the matching gap in the drive channel
on the drive drawer.
Raised button on the right side of the drive carrier
e. Lower the drive straight down, and then rotate the cam handle down until the drive snaps into place
under the orange release latch.
f. Repeat the previous substeps for each drive in the drawer.
You must be sure that slots 0, 3, 6, and 9 in each drawer contain drives.
g. Carefully push the drive drawer back into the enclosure.
