3. Cable port pair 1c/2d on each controller to stack 2:
This is the multipathed cabling for stack 2.
a. Cable controller 1 port 1c to stack 2, first shelf IOM A port 1.
b. Cable controller 2 port 1c to stack 2, first shelf IOM B port 1.
c. Cable controller 1 port 2d to stack 2, last shelf IOM B port 3.
d. Cable controller 2 port 2d to stack 2, last shelf IOM A port 3.
4. Cable port pair 2c/1b on each controller to stack 2:
This is the quad-pathed cabling for stack 2. Once completed, stack 2 has quad-pathed connectivity to each
controller.
a. Cable controller 1 port 2c to stack 2, first shelf IOM A port 2.
b. Cable controller 2 port 2c to stack 2, first shelf IOM B port 2.
c. Cable controller 1 port 1b to stack 2, last shelf IOM B port 4.
d. Cable controller 2 port 1b to stack 2, last shelf IOM A port 4.
Maintain
Hot-swap a disk drive in a DS224C or DS212C disk shelf - shelves with IOM12
modules
You can hot-swap a failed disk drive in a DS224C or DS212C disk shelf.
Before you begin
• The disk drive that you are installing must be supported by the DS224C or DS212C disk shelf.
NetApp Hardware Universe
• All other components in the system must be functioning properly; if not, contact technical support.
• The disk drive you are removing must be failed.
You can verify the disk drive is failed by running the
storage disk show -broken command. The
failed disk drive appears in the list of failed disk drives. If it does not, you should wait, and run the
command again.
Depending on the disk drive type and capacity, it can take up to several hours for the disk
drive to appear in the list of failed disk drives.
• If you are replacing a self-encrypting disk (SED), you must follow the instructions for Replacing an SED in
the ONTAP documentation for your version of ONTAP.
Instructions in the ONTAP documentation describe additional steps you must perform before and after
replacing an SED.
NetApp encryption overview with the CLI
About this task
1612
