NetApp E2760 Replacement Manual

9
3 Pull the levers on the side of the drive drawer until the drive drawer stops.
IMPORTANT You must add the drives to the same location in the drive drawer that they were in
before the drive drawer was removed.
4 Install all of the drives into the drive drawer. To install a drive:
a Raise the handle on the drive to the vertical position.
b Align the two raised buttons on each side over the matching gap in the drive channel on the
drive drawer (Figure 10).
Figure 10 Drive with Raised Handle – Side View
1 Raised Buttons
c Lower the drive straight down, and then rotate the drive handle down until the drive snaps into
place under the drive release lever (Figure 11).
Figure 11 Drive Release Lever Locked by the Drive Handle
1. Drive Release Lever
2. Drive Handle
92012-02
1
