NetApp E2824 Install And Setup

Install hardware from the bottom of the rack or cabinet up to the top to prevent the
equipment from toppling over.
3. Install the shelf.
When fully loaded with drives, each shelf weighs approximately 64 lb (29 kg). Two persons
or mechanical lift are required to safely move the shelf.
a. Starting with the shelf you want at the bottom of the cabinet, place the back of the shelf (the end with
the connectors) on the rails.
b. Supporting the shelf from the bottom, slide it into the cabinet.
4

NetApp E2824 Specifications

General

Model	E2824
Category	Storage
Form Factor	2U
Drive Bays	24
Maximum Raw Capacity	1.8PB
Host Interface	12 Gb/s SAS
RAID Support	Yes
Hot-Swap Drives	Yes
RAID Levels	0, 1, 5, 6, 10
Power Supply	Dual redundant
Drive Type	SAS, SSD
Host Connectivity	12Gb/s SAS
Controller	Dual active controllers
