NetApp E2824 Install And Setup

4. Secure the shelf.
Secure the shelf to the rack as directed in
Rack-mount hardware.
a. Insert screws into the first and third holes from the top of the shelf on both sides to secure it to the front
of the cabinet.
b. Place two back brackets on each side of the upper rear section of the shelf. Insert screws into the first
and third holes of each bracket to secure the back of the cabinet.
5

NetApp E2824 Specifications

General

Model	E2824
Category	Storage
Form Factor	2U
Drive Bays	24
Maximum Raw Capacity	1.8PB
Host Interface	12 Gb/s SAS
RAID Support	Yes
Hot-Swap Drives	Yes
RAID Levels	0, 1, 5, 6, 10
Power Supply	Dual redundant
Drive Type	SAS, SSD
Host Connectivity	12Gb/s SAS
Controller	Dual active controllers
