Connecting to the Internet
8
NETGEAR DOCSIS 3.0 N450 Wi-Fi Data Gateway
Gateway Rear Panel
Ethernet LAN ports
Coaxial cable connector
USB port
Power adapter input
Reset button
Figure 2. Gateway rear panel
The rear panel includes the following connectors, viewed from top to bottom:
• Four Gigabit Ethernet LAN ports.
To connect local computers, use these ports.
• USB port.
To connect a USB hard drive, flash drive, or printer, use this port.
• Reset. T
o set the gateway to the original factory settings, press and hold the Reset
button for over 7 seconds. See Factory Default Settings on page 54.
• Coaxial cable connector.
Attach a coaxial cable to the cable service provider’s
connection.
• Power. Power adapter input.
