Front View
Click to enlarge.
After the cable modem successfully registers on the network, the Power, Upstream,
Downstream, and Internet indicators illuminate continuously to indicate that the modem is
online and fully operational. For more details, refer to the Modem Lights section.
Back View
Click to enlarge.
The modem includes the following connection ports:
Ethernet – Connects to the Gigabit Ethernet cable.
Reset – Use this button in the unlikely event that you want to restore the default factory
settings. This button is recessed to prevent accidental resets of your modem.
Cable / Internet – Connect your coaxial cable line to this port.
Power – Connect the supplied power cord to this port.
On / Off – Turns modem on and off.
To Next Page
