NETGEAR EAX14 User Manual

3. Make sure that the Router Link LED remains lit.
4. Log in to your extender:
a.
Launch a web browser from a computer or mobile device that is connected to
your extender network.
b. Log in to your extender:
•
If you did not enable the One WiFi Name feature, enter
http://www.mywifiext.net/ in the address field of the browser.
•
If you enabled the One WiFi Name feature, enter one of the following URLs:
-
Windows-based computers. http://mywifiext/
or http://mywifiext.local/
-
Mac computers, iOS devices, and Linux devices. http://mywifiext.local/
-
Android devices. http://<extender’s IP address>/ (for example,
http://192.168.1.3/)
A login page displays.
c. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
5. Select Settings > Connected Devices.
The Connected Devices page displays the MAC addresses and virtual MAC addresses
for computers and WiFi devices that are connected to the extender network.
6. On the router, add the extender’s virtual MAC address and all the virtual MAC
addresses connected to the extender network to your router’s MAC filter table.
Note: To reserve a specific IP address for the extender, you must specify the first
virtual MAC address that displays for your extender’s 2.4 GHz or 5 GHz network in
your router’s IP reservation table. (The first virtual MAC address that displays for your
extender’s 2.4 GHz and 5 GHz networks is the same.)
7.
Enable the router’s MAC filter, wireless access control, or ACL.
User Manual46Extender Network Settings
AX1800 4-Stream WiFi 6 Mesh Extender

NETGEAR EAX14 Specifications

Operating Environment

operating temperature	32° to 104°F (0° to 40°C)
operating humidity	90% maximum relative humidity, noncondensing

Ports & interfaces

ethernet port speed	10/100/1000 Mbps
wireless standards	802.11a/b/g/n/ac/ax and 802.11k

Weight and Dimensions

dimensions	5.9 x 2.7 x 2.1 in (149.86 x 68.58 x 53.34 mm)
weight	0.49 lb (222 g)
