NETGEAR EX2700 Installation Guide

2
Getting Started
The NETGEAR WiFi Range Extender increases the distance of a WiFi
network by boosting the existing WiFi signal and enhancing the overall
signal quality over long distances. An extender repeats the signals from an
existing WiFi router or access point.
Existing WiFi
Sometimes your router
does not provide the WiFi
coverage you need.
WiFi Range
Extender
Boosts the range of your
existing WiFi and creates
a stronger signal in
hard-to-reach areas.

NETGEAR EX2700 Specifications

General

Type	Network repeater
Maximum transfer distance	- m
External power adapter	No
On/off switch	Yes
Product color	White
LED indicators	Power, WPS
Antennas quantity	2
Bandwidth	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA, WPA2-PSK
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	34 mm
Width	55 mm
Height	67 mm
Weight	98 g
