ReferenceManualforthe Model FR114P,FR114W andFM114P Cable/DSLProSafeFirewall Family
10-6 Troubleshooting
OR
Configure your firewall to spoof your PC’s MAC address. This can be done in the Basic
Settings menu. Refer to “Manual Configuration“ on page 4-8.
If your firewall can obtain an IP address, but your PC is unable to load any web pages from the
Internet:
• Your PC may not recognize any DNS server addresses.
A DNS server is a host on the Internet that translates Internet names (such as www addresses)
to numeric IP addresses. Typically your ISP will provide the addresses of one or two DNS
servers for your use. If you entered a DNS address during the firewall’s configuration, reboot
your PC and verify the DNS address as described in “Verifying TCP/IP Properties“ on page
3-5. Alternatively, you may configure your PC manually with DNS addresses, as explained in
your operating system documentation.
• Your PC may not have the firewall configured as its TCP/IP gateway.
If your PC obtains its information from the firewall by DHCP, reboot the PC and verify the
gateway address as described in “Verifying TCP/IP Properties“ on page 3-5.
Troubleshooting a TCP/IP Network Using a Ping Utility
Most TCP/IP terminal devices and routers contain a ping utility that sends an echo request packet
to the designated device. The device then responds with an echo reply. Troubleshooting a TCP/IP
network is made very easy by using the ping utility in in your PC or workstation.
Testing the LAN Path to Your Firewall
You can ping the firewall from your PC to verify that the LAN path to your firewall is set up
correctly.
To ping the firewall from a PC running Windows 95 or later:
1. From the Windows toolbar, click on the Start button and select Run.
2. In the field provided, type Ping followed by the IP address of the firewall, as in this example:
ping 192.168.0.1
3. Click on OK.
You should see a message like this one:
