NETGEAR FVS336G User Manual

ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336G Reference Manual
Introduction 1-7
v1.0, October 2007
Rear Panel Features
The rear panel of the ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN includes
Gigabit Ethernet LAN and WAN connections, a cable lock receptacle, power and reset switches,
and an AC power connection.
Viewed from left to right, the rear panel contains the following elements:
1. Factory Defaults button.
Using a sharp object, press and hold this button for about ten seconds until the front panel
TEST light flashes to reset the VPN firewall to factory default settings. All configuration
settings will be lost and the default password will be restored.
2. LAN Ethernet ports.
Four switched N-way automatic speed negotiating, Auto MDI/MDIX, Gigabit Ethernet ports
with RJ-45 connectors.
LINK/ACT
(Link and
Activity)
On (Green)
Blinking (Green)
Off
The WAN port has detected a link with a connected Ethernet device.
Data is being transmitted or received by the WAN port.
The WAN port has no link.
LAN Ports
SPEED On (Green)
On (Amber)
Off
The LAN port is operating at 1,000 Mbps.
The LAN port is operating at 100 Mbps.
The LAN port is operating at 10 Mbps.
LINK/ACT
(Link and
Activity)
On (Green)
Blinking (Green)
Off
The WAN port has detected a link with a connected Ethernet device.
Data is being transmitted or received by the WAN port.
The WAN port has no link.
Figure 1-2
Table 1-1. LED Descriptions (continued)
Object Activity Description

NETGEAR FVS336G Specifications

General

Model	FVS336G
Category	Firewall
WAN Ports	2
VPN Support	Yes
SPI Firewall	Yes
QoS	Yes
Max VPN Tunnels	25
Encryption	3DES, AES
Protocols	IPSec, PPTP
Authentication	SHA-1, MD5
Dimensions	9.5 x 6.5 x 1.7 inches
Weight	1.5 kg (3.3 lb)
