NETGEAR GS316 Installation Guide

©NETGEAR,Inc.,NETGEARandthe
NETGEARLogoaretrademarksof
NETGEAR,Inc.Anynon-NETGEAR
trademarksareusedforreference
purposesonly.
NETGEAR, Inc.
350EastPlumeriaDrive
SanJose,CA95134,USA
NETGEAR INTERNATIONAL LTD
Floor1,Building3
UniversityTechnologyCentre
CurraheenRoad,Cork,
T12EF21,Ireland
Support and Community
Regulatory and Legal
SiceproduitestvenduauCanada,vouspouvezaccéderàcedocumentenfrançais
canadienàhttps://www.netgear.com/support/download/.
(IfthisproductissoldinCanada,youcanaccessthisdocumentinCanadianFrenchat
https://www.netgear.com/support/download/.)
ForregulatorycomplianceinformationincludingtheEUDeclarationofConformity,visit
https://www.netgear.com/about/regulatory/.
Seetheregulatorycompliancedocumentbeforeconnectingthepowersupply.
ForNETGEAR’sPrivacyPolicy,visithttps://www.netgear.com/about/privacy-policy/.
Byusingthisdevice,youareagreeingtoNETGEAR’sTermsandConditionsat
https://www.netgear.com/about/terms-and-conditions/.Ifyoudonotagree,returnthe
devicetoyourplaceofpurchasewithinyourreturnperiod.
Donotusethisdeviceoutdoors.
Visitnetgear.com/supporttogetyourquestionsansweredandaccessthelatest
downloads.
YoucanalsocheckoutourNETGEARCommunityforhelpfuladviceat
community.netgear.com.
Specication Description
Networkinterface RJ-45connectorfor1000BASE-T,100BASE-TX,or10BASE-T
Networkcable Category5e(Cat5e)orhigherratedEthernetcable
Ports 16
Power 100-240VAC50/60Hz,1.0A
Powerconsumption 8.4Wmax.
Weight 1.86lb.(0.84kg)
Dimensions(WxDxH) 11.3x4.0x1.0in(286x101x26mm)
Operatingtemperature 32–104°F(0–40°C)
Operatinghumidity 10%–90%relativehumidity,noncondensing
SpecicationsAttach the switch to a wall
Toattachtheswitchtoawall,youneedthewall-mountscrewsthataresuppliedwiththe
switch.
To attach the switch to a wall:
1. Locatethetwomountholesonthebottompaneloftheswitch.
2. Markanddrilltwomountingholesinthewallwhereyouwanttomounttheswitch.
Thetwomountingholesmustbe5.67in.(144mm)apart,center-to-center.
3. InsertthesuppliedanchorsintothewallandtightenthesuppliedscrewswithaNo.2
Phillipsscrewdriver.
Leaveabout0.125in.(4mm)ofeachscrewprotrudingfromthewallsothatyoucan
insertthescrewsintotheholesonthebottompanel.

NETGEAR GS316 Specifications

General

Switch type	Unmanaged
Quality of Service (QoS) support	Yes
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
Stackable	-
Certification	CE Mark, FCC Part 15 Class A, IC Class A, RCM, CCC, VCCI, KC
On/off switch	No
Product color	Black
LED indicators	Activity, Link, Power, Speed
Housing material	Metal
Jumbo frames	9216
Forwarding rate	1.448 Mpps
Latency (1 Gbps)	3.9 µs
MAC address table	16000 entries
Packet buffer memory	0.768 MB
Packet forwarding rate (1 Gbps)	1448000 pps
Mean time between failures (MTBF)	9041798 h
Heat dissipation	2873 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Input voltage	12 V
Output current	1 A
Power consumption (max)	8.4 W
Networking standards	IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Package type	Box
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	101 mm
Width	286 mm
Height	26 mm
Weight	840 g
