NETGEAR N450 User Manual

Connecting to the Internet
9
N450 WiFi Cable Modem Router Model N450/CG3000Dv2
Back Panel
The back panel has the following ports, button, and connector:
Figure 3. Modem router rear panel
The rear panel includes the following connectors and button, viewed from top to bottom:
• Four Gigabit LAN ports. To connect local computers, use these ports.
• USB port. To connect a USB hard drive, flash drive, or printer, use this port.
• Reset. To set the modem router to the original factory settings, press and hold the Reset
button for over seven seconds. See
Factory Default Settings on page 86.
• Coaxial cable connector. Attach a coaxial cable to the cable service provider’s
connection.
• Power. Power adapter input.
LAN ports
Coaxial cable connector
USB port
Power adapter input
Reset button

NETGEAR N450 Specifications

General

Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	450 Mbit/s
USB port	Yes
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Security algorithms	WPA, WPA2, WPA2-PSK, WPS
Cables included	LAN (RJ-45)
Product type	Tabletop router
Product color	Black
DSL WAN	No
Power source type	DC

Weight and Dimensions

Depth	93 mm
Width	165 mm
Height	259 mm
Weight	590 g
